Four independent channels of gating
Independent key filtering
Independent Threshold and Release controls
Differentially balanced gold-plated XLR and 1/4" inputs and outputs
True RMS level detection
Stereo Coupling mode
Switchable +4dBu or -10dBv operation per channel
| Input Connectors | XLR (Pin 2 and tip hot) |
| Input Type | Electronically balanced/unbalanced, RF filtered |
| Input Impedance | Balanced > 50 kOhm, unbalanced >25 kOhm |
| Max Input | > +22 dBu balanced or unbalanced |
| CMRR | 40dB: Typically >55 dB at 1 kHz |
| Key Input | Electronically balanced/unbalanced, RF fitered Balanced 50kOhm, unbalanced > 25 kOhm |
| Output Connectors | XLR (Pin 2 hot) |
| Output Type | Servo-balanced/unbalanced, RF filtered |
| Output Impedance | Balanced 60 Ohm, unbalanced 30 Ohm |
| Max Output | > +22 dBm balanced, > +20 dBm unbalanced |
| Bandwidth | 20 Hz to 20 kHz, +0/-0.5 dB |
| Frequency Response | 0.35 Hz to 200 kHz, +0/-3 dB |
| Noise | < -96 dBu, unweighted, 22 kHz measurement bandwidth |
| Dynamic Range | > 115 dB, unweighted |
| THD+Noise | 0.008% typical at +4 dBu (1 kHz unity gain), 0.08% typical at +20 dBu (1 kHz unity gain), < 0.1% any amount of compression up to 40 dB, 1 kHz |
| Interchannel Crosstalk | < -80dB, 20 Hz to 20 kHz |
| Stereo Coupling | True RMS Power Summing |
| Operating Voltage | 100-120 VAC 50-60 Hz or 200-240 VAC 50/60 Hz |
| Power Consumption | 30 Watts |
| Fuse | 100-120 VAC:250 mA Slow Blow, 200-240 VAC:125 mA Type T |
| Power Connector | IEC receptacle |
| 设备重量 | 6.9 lbs. |
| Shipping Weight | 9.3 lbs. |
